NG16 1/2″ High/Low Pressure Block HLUV

Name: NG16 1/2" High/Low Pressure Block HLUV
Brand: Cohimar
SKU: 460
Availability: InStock

SKU 460 Categoría: Hydraulic components Brand: OFC

The NG16 1/2″ High/Low Pressure Block HLUV is a compact hydraulic module that provides a high‑pressure side (20‑260 bar) and a low‑pressure side (5‑120 bar) in a single unit. It features NG16 1/2″ threaded ports, a flow capacity of 80 L/min, and a steel housing with corrosion‑resistant coating. Designed for mobile machinery, industrial presses, agricultural equipment and marine systems, it complies with ISO 4413 and EN 853 standards. Immediate stock availability – contact Cohimar for pricing and delivery details.

Description

Description

.tg {border-collapse:collapse;border-spacing:0;}
.tg td{border-style:solid;border-width:0px;font-family:Arial, sans-serif;font-size:14px;overflow:hidden;
padding:10px 5px;word-break:normal;}
.tg th{border-style:solid;border-width:0px;font-family:Arial, sans-serif;font-size:14px;font-weight:normal;
overflow:hidden;padding:10px 5px;word-break:normal;}
.tg .tg-lboi{border-color:inherit;text-align:left;vertical-align:middle}
.tg .tg-9wq8{border-color:inherit;text-align:center;vertical-align:middle}

REFERENCIA	ALTA	BAR	BAJA	BAR	LPM
OFC-HLUVNG161020	1/2″	20-260	3/4″	5-120	80

Construction equipment hydraulic circuits
Industrial press dual‑pressure systems
Agricultural machinery hydraulic networks
Marine deck machinery with high/low pressure requirements

High‑pressure rating 20–260 bar, low‑pressure rating 5–120 bar, flow capacity 80 L/min, NG16 1/2″ threaded connections, steel construction with corrosion‑resistant coating.
