The NG 10 rear‑outlet steel hydraulic block provides 1 to 8 high‑pressure rear connections in a compact, corrosion‑resistant steel housing. Designed for mobile hydraulic equipment, agricultural machinery, construction excavators and industrial presses, it complies with ISO 4413 standards and features standard BSP fittings. Dimensions range from 80 mm × 56 mm (1 outlet) to 640 mm × 616 mm (8 outlets) with weights from 5.8 kg to 45.6 kg. All models are in immediate stock; contact Cohimar for pricing and delivery.
| REFERENCIA | NUM. ESTACIONES | X | Y | PESO KG |
|---|---|---|---|---|
| BLO-MRK5-1G | 1 | 80 | 56 | 5,8 |
| BLO-MRK5-2G | 2 | 160 | 136 | 11,3 |
| BLO-MRK5-3G | 3 | 240 | 216 | 17 |
| BLO-MRK5-4G | 4 | 320 | 296 | 22,7 |
| BLO-MRK5-5G | 5 | 400 | 376 | 28,5 |
| BLO-MRK5-6G | 6 | 480 | 456 | 34,2 |
| BLO-MRK5-7G | 7 | 560 | 536 | 39,9 |
| BLO-MRK5-8G | 8 | 640 | 616 | 45,6 |
Available in 1‑to‑8 rear‑outlet configurations, with compact dimensions (X 80‑640 mm, Y 56‑616 mm) and weights from 5.8 kg to 45.6 kg. Constructed from high‑strength steel and compliant with ISO 4413 hydraulic standards.
