The Manual Light Series P Aluminum Pump is a lightweight, high‑pressure hand pump made of aluminium alloy. Available in 1‑stage and 2‑stage versions, it handles oil volumes from 327 to 2 540 cm³, displacements up to 39.33 cm³/rev and a maximum pumping force of 43 kN. Designed for hydraulic presses, metal‑forming equipment and field service, it meets ISO standards and is stocked for immediate delivery. Contact Cohimar for pricing and availability.
| REFERENCIA | TIPO DE BOMBA | Cantidad Aceite utilizable (cm³) | Desplazamiento 1a etapa | 2a etapa | Fuerza Máx Bombeo |
|---|---|---|---|---|---|
| EN-P141 | 1 etapa | 327 | – | 0,9 | 32,7 |
| EN-P391 | 1 etapa | 901 | – | 2,47 | 38,6 |
| EN-P142 | 2 etapas | 327 | 3,62 | 0,9 | 35,4 |
| EN-P202 | 2 etapas | 901 | 3,62 | 0,9 | 28,6 |
| EN-P392 | 2 etapas | 901 | 11,26 | 2,47 | 42,2 |
| EN-P802 | 2 etapas | 2540 | 39,33 | 2,47 | 43,1 |
| EN-P842 | 2 etapas | 2540 | 39,33 | 2,47 | 43,1 |
Offers 1‑stage and 2‑stage configurations with oil capacities from 327 cm³ to 2 540 cm³, displacements up to 39.33 cm³ per stroke and a maximum pumping force of 43 kN.
