SAE 90° Threaded Flange

Categoría: Brand:

The SAE 90° Threaded Flange is a steel accessory for press‑fit hydraulic and pneumatic systems, offering right‑angle connections with metric and UNC threads. Sizes cover 1/2″ to 1 ½” nominal diameters, pressure ratings from 22 bar up to 348 bar, and conform to SAE standards. Ideal for gas, oil, and water circuits in industrial machinery, it provides a robust, leak‑free joint. Immediate stock availability – contact Cohimar for pricing and delivery options.

Description

Gas Acero



S.A.E.

 TORNILLOS
METR. U.N.C.
1/2″ M8 x 30 5/16″ x1″1/4
3/4″

M10 x 35

 3/8″ x 1″ 1/2
1″
1″ 1/4 7/16″ x 1″ 3/4
1″ 1/2 M12 x 45 1/2″ x 1″ 3/4



Serie 3000



REFERENCIA

 PRES. MAX.

(BAR)

 DIMENSIONES
A B C D E F G H I L M N
V-AFS180/90G

348

 1/2″ 17,48 8,5 38,1 59 13,5 18 17 57 36 19 31
V-AFS200/90G 3/4″ 22,23 10,5 47,63 63 19 22 18 68 38 19 39
V-AFS202/90G 1″ 26,19 10,5 52,37 68 25 28 19 74 41 19 45
V-AFS204/90G 279 1″ 1/4 30,18 11,5 58,72 84 32 30 22 81 50 22 54
V-AFS206/90G 210 1″ 1/2 35,7 13,5 69,9 97 38 36 25 95 58 24 63
  • Hydraulic power units
  • Pneumatic compressor manifolds
  • Gas distribution networks
  • Industrial machinery requiring right‑angle connections

Available in sizes 1/2″‑1 ½” with metric and UNC threads; pressure rating up to 348 bar for the 1/2″ model, decreasing for larger diameters.
