The APL 300 Heat Exchanger with Thermostat is a compact steel unit for hydraulic oil cooling, featuring integrated thermostat control and an electro‑ventilator. It supports oil flow rates of 20‑150 L/min, operates at 12 V or 24 V with a power consumption of 190 W, and provides 1.7 m³/h of air flow for efficient heat removal. Standard 2‑inch inlet/outlet ports fit common hydraulic fittings. Designed for hydraulic power units, mobile equipment, and process plant oil circuits. In stock and ready for immediate delivery – request a quote today.
| REFERENCIA | CAUDAL ACEITE L/MIN | VOLTAGE V | POTENCIA W | CORRIENTE A | FLUJO AIRE M3/H | PESO | CAPACIDAD IT | Ø | RECAMBIO ELECTROVENTILADOR |
|---|---|---|---|---|---|---|---|---|---|
| SES-3RL30012T247 | 20-150 | 12 | 190 | 14,8 | 1.700 | 10 | 2 | 280 | SES-1VNAPL30012C |
| SES-3RL30024T247 | 20-150 | 24 | 190 | 7,4 | 1.700 | 10 | 2 | 280 | SES-1VNAPL30024C |
Oil flow capacity 20‑150 L/min, power 190 W, operating voltage 12 V or 24 V, air‑flow 1.7 m³/h, compact 10 kg unit with 2‑inch inlet/outlet ports.
