The BC 250/2 heat exchanger with thermostat and connection box provides reliable oil cooling for hydraulic systems. It supports 30‑180 L/min flow, 4 L capacity, and 180 W dissipation, available in 12 V (15 A) or 24 V (7.5 A) versions with a 2.2 m³/h cooling fan. Built from robust steel, it fits metal‑working presses, mobile equipment, machining centers and power units. Immediate stock – request a quote from Cohimar.
| REFERENCIA | CAUDAL ACEITE L/MIN | CAPACIDAD L | VOLTAGE V | POTENCIA W | CORRIENTE A | FLUJO AIRE M3/H | PESO KG | RECAMBIO ELECTROVENTILADOR |
|---|---|---|---|---|---|---|---|---|
| SES-3RBC250/212T247I | 30-180 | 4 | 12 | 180 | 15 | 2.200 | 14 | SES-1VNAPL30012C |
| SES-3RBC250/224T247I | 30-180 | 4 | 24 | 180 | 7,5 | 2.200 | 14 | SES-1VNAPL30024C |
Oil flow 30‑180 L/min, capacity 4 L, power 180 W; available in 12 V (15 A) or 24 V (7.5 A) with 2.2 m³/h air‑cooling fan; weight 14 kg.
