The BC390 Heat Exchanger with Thermostat is a compact oil‑to‑air cooler for hydraulic and machine‑tool circuits. It manages oil flow rates of 20‑250 L/min, offers a 5 L thermal capacity, and operates on either 12 V or 24 V (240 W). Constructed from steel housing with aluminium fins, it includes an integrated fan delivering 2 500 m³/h of air. CE‑marked and supplied with standard flange connections, the unit is ready for immediate installation. Stock available – request a quote today.
| REFERENCIA | CAUDAL ACEITE L/MIN | CAPACIDAD L | VOLTAGE V | POTENCIA W | CORRIENTE A | FLUJO AIRE M3/ H | PESO KG | RECAMBIO ELECTROVENTILADOR |
|---|---|---|---|---|---|---|---|---|
| SES-3RBC39012T247 | 20-250 | 5 | 12 | 240 | 20 | 2.500 | 16 | SES-1MCVA18AP70AC |
| SES-3RBC39024T247 | 20-250 | 5 | 24 | 240 | 10 | 2.500 | 16 | SES-1VNAPL58024C |
Oil flow range 20‑250 L/min, 5 L capacity, 12 V/24 V options, 240 W power, integrated thermostat and fan, weight 16 kg.
