Description
| REFERENCIA | INT | EXT | PRESIÓN | RADIO CURVATURA |
|---|---|---|---|---|
| A-186AA-6×14 | 6 | 14 | 20 | 48 |
| A-186AA-8×17 | 8 | 17 | 20 | 64 |
| A-186AA-10×19 | 10 | 19 | 20 | 80 |
| A-186AA-13×23 | 13 | 23 | 20 | 104 |
| A-186AA-19×30 | 19 | 30 | 20 | 152 |
| A-186AA-25×37 | 25 | 37 | 20 | 200 |
20 Bar Heavy Duty Air/Water Hammer Hose
The 20 Bar Heavy‑Duty Air/Water Hammer Hose is a reinforced hydraulic hose designed for high‑pressure air and water transport in industrial systems. It features internal diameters from 6 mm to 25 mm, external diameters from 14 mm to 37 mm, and curvature radii ranging 48‑200 mm. Constructed from a synthetic rubber core, steel wire braid and a durable outer jacket, it meets international standards for heavy‑duty pneumatic and hydraulic applications. Ideal for cooling circuits, pneumatic conveying, high‑pressure cleaning and air supply lines. In stock for immediate shipment – request a quote today.
- Hydraulic cooling circuits
- Pneumatic conveying systems
- High‑pressure water cleaning
- Industrial air supply lines
Pressure rating 20 bar, internal diameters 6‑25 mm, external diameters 14‑37 mm, curvature radius 48‑200 mm. Heavy‑duty reinforced construction suitable for air and water.
