Radiator Hose 5 Bar

SKU 582 Categoría:

The Radiator Hose 5 Bar is a flexible, reinforced coolant hose for industrial cooling systems. It handles internal diameters from 13 mm to 127 mm (external 21 mm‑141 mm) and is rated for a continuous pressure of 5 bar. Constructed from a rubber core with a textile braid, it offers excellent resistance to abrasion and coolant chemicals. Ideal for machine tool radiators, heat exchangers, and process plant cooling loops. Available in stock with standard clamps and fittings; custom lengths can be supplied on request. Contact Cohimar for pricing and delivery details.

Description

REFERENCIA INT EXT PRESIÓN BAR PESO KG/MT
A-352AA-13×21 13 21 5 0,280
A-352AA-16×24 16 24 5 0,330
A-352AA-18×26 18 26 5 0,360
A-352AA-20×28 20 28 5 0,390
A-352AA-22×30 22 30 5 0,420
A-352AA-25×33 25 33 5 0,470
A-352AA-28×36 28 36 5 0,510
A-352AA-30×38 30 38 5 0,540
A-352AA-32×40 32 40 5 0,570
A-352AA-35×43 35 43 5 0,620
A-352AA-38×48 38 48 5 0,850
A-352AA-40×50 40 50 5 0,890
A-352AA-42×52 42 52 5 0,930
A-352AA-45×55 45 55 5 0,980
A-352AA-48×58 48 58 5 1,040
A-352AA-51×61 51 61 5 1,110
A-352AA-55×65 55 65 5 1,180
A-352AA-57×67 57 67 5 1,220
A-352AA-60×70 60 70 5 1,280
A-352AA-63×73 63 73 5 1,340
A-352AA-70×80 70 80 5 1,440
A-352AA-76×86 76 86 5 1,550
A-352AA-80×90 80 90 5 1,630
A-352AA-90×102 90 102 5 2,010
A-352AA-102×114 102 114 5 2,250
A-352AA-110×122 110 122 5 2,410
A-352AA-115×127 115 127 5 2,510
A-352AA-127×141 127 141 5 3,200
  • Cooling circuits of industrial machinery
  • Heat exchangers in power plants
  • Hydraulic system radiators in mobile equipment
  • Process plant coolant loops

Rated for 5 bar continuous pressure; size range from 13 × 21 mm to 127 × 141 mm; weight per metre from 0.280 kg to 3.200 kg.
