The Inline Rotary Coupling SJL series offers a robust, corrosion‑resistant carbon‑steel solution for rotating hydraulic lines. Available in BSP thread sizes 1/4″, 3/8″, 1/2″, 3/4″ and 1″, the couplings handle pressures up to 400 bar (smaller sizes) and flow rates from 19 to 150 L/min. Designed for mobile machinery, construction equipment, and industrial presses, they provide smooth rotation and easy installation. All sizes are in stock – contact Cohimar for a quotation.
| REFERENCIA | ROSCA | A | B | C | H1 | H2 | LPM | PRESIÓN MAX |
|---|---|---|---|---|---|---|---|---|
| OFC-SJL01 | 1/4″ | 63 | 42 | 34 | 19 | 30 | 25 | 400 |
| OFC-SJL02 | 3/8″ | 66,5 | 44 | 37,5 | 22 | 32 | 45 | 400 |
| OFC-SJL03 | 1/2″ | 70,4 | 44 | 39,5 | 27 | 32 | 80 | 360 |
| OFC-SJL04 | 3/4″ | 90,7 | 60 | 49,5 | 32 | 41 | 120 | 310 |
| OFC-SJL05 | 1″ | 100 | 65 | 54,5 | 41 | 46 | 150 | 280 |
Pressure rating up to 400 bar for 1/4″ and 3/8″ sizes; flow capacity from 19 L/min (1/4″) to 150 L/min (1″); compact dimensions A 63‑100 mm, B 42‑65 mm, C 34‑54.5 mm.
