The EV220A is a brass‑body low‑pressure valve featuring an NBR rubber seat and a Kv flow coefficient from 1 to 7. Designed for hydraulic and pneumatic systems operating between 0.2 and 16 bar, it is offered in thread sizes from 1/4″ to 1″ (DN6 to DN22). Ideal for material‑handling machinery, cooling circuits, and low‑pressure lubrication lines, the valve complies with European low‑pressure standards. Cohimar holds stock of all variants for fast delivery; contact us for a quotation.
| REFERENCIA | ROSCA | JUNTA | CAUDAL | PASO | PRESIÓN |
| D-042U4053 | 1/4″ | NBR | Kv1 M3/H | DN6 | 0,2-16 BAR |
| D-042U4063 | 3/8″ | NBR | Kv1 M3/H | DN10 | 0,2-16 BAR |
| D-042U4064 | 1/2″ | NBR | Kv1,6 M3/H | DN10 | 0,2-10 BAR |
| D-042U4082 | 3/4″ | NBR | Kv7 M3/H | DN18 | 0,3-16 BAR |
| D-042U4092 | 1″ | NBR | Kv7 M3/H | DN22 | 0,3-16 BAR |
Brass body with NBR seat, Kv range 1‑7, pressure rating 0.2‑16 bar (0.2‑10 bar for 1/2″ size), thread sizes 1/4″‑1″.
