The RH and DRH type non‑return valves provide one‑way flow protection for medium and high pressure hydraulic systems, featuring an integrated unlocking mechanism for fast maintenance. Available in pressure ratings up to 700 bar (RH) and 500 bar (DRH) with flow capacities from 15 to 100 L/min. Constructed from forged steel and compliant with EN/ISO standards, they fit standard hydraulic fittings and are ideal for mobile machinery, industrial presses, and high‑pressure plant circuits. Stocked for immediate delivery – contact Cohimar for pricing and technical assistance.
| REFERENCIA | MODELO | PRESIÓN BAR | CAUDAL (L/MIN) | SÍMBOLO |
|---|---|---|---|---|
| HAWE-7610 5001-00 | RH1 | 700 | 15 | |
| HAWE-7610 5002-00 | RH2 | 700 | 35 | |
| HAWE-7610 5003-00 | RH3 | 500 | 55 | |
| HAWE-7610 5004-00 | RH4 | 500 | 100 | |
| HAWE-7611 0005-00 | DRH1 | 500 | 16 | |
| HAWE-7611 0001-00 | DRH2 | 500 | 30 | |
| HAWE-7611 0002-00 | DRH3 | 500 | 60 |
Pressure rating up to 700 bar (RH) and 500 bar (DRH); flow range 15‑100 L/min across seven model variants; built‑in unlocking mechanism for quick maintenance.
