Flat-Faced Female Hydraulic Plug ISO 16028

SKU 415 Categoría: Brand:

The Flat-Faced Female Hydraulic Plug ISO 16028 is a high‑pressure sealing component for hydraulic circuits. It is used to block or seal line ends in mobile machinery, plant maintenance, and test rigs. Available in DN6 to DN25 sizes with BSP and SAE UNF threads, it offers a working pressure of 350 bar and a burst rating of 1 400 bar. Constructed from carbon steel with a protective coating, the plug complies with ISO 16028 standards. Immediate stock is available – request a quotation today.

Description

REFERENCIA DN ROSCA d1 Presión Trabajo Bar Presión Rotura Bar D1 mm CH mm L1 mm L mm
A-R1Q-1229101 6 1/4″ BSP 350 1400 26 22 57,8 97
A-R1Q-1229102 10 3/8″ BSP 350 1400 32 27 69,3 117
A-R1Q-1224380 10 1/2″ BSP 350 1400 32 27 69,3 117
A-R1Q-1229103 13 1/2″ BSP 350 1400 38 32 74,5 125
A-R1Q-1224381 13 3/4″ BSP 350 1400 38 32 74,5 125
A-R1Q-1232287 16 3/4″BSP 350 1400 40 34 81,3 134
A-R1Q-1229105 19 3/4″ BSP 350 1400 48 42 93 156
A-R1Q-1224382 19 1″ BSP 350 1400 48 42 93 156
A-R1Q-1231464 25 1″ BSP 350 1400 55 50 101 177
A-R1Q-1229106 25 1″ 1/4 BSP 350 1400 55 50 101 177
A-R1Q-1229236 10 9/16″-18 SAE UNF 350 1400 32 27 69,3 117
A-R1Q-1229238 13 3/4″-16 SAE UNF 350 1400 38 32 74,5 125
A-R1Q-1232384 16 1″ 1/16-12 SAE UNF 350 1400 40 34 81,3 134
A-R1Q-1229241 19 1″ 1/16-12 SAE UNF 350 1400 48 42 93 156
A-R1Q-1229243 25 1″ 5/16-12 SAE UNF 350 1400 55 50 101 177
A-R1Q-1231469 10 MET 22×1,5 350 1400 32 27 69,3 117
  • Sealing of hydraulic circuit ends in mobile machinery
  • Pressure testing of hydraulic lines
  • Temporary line blockage during plant maintenance
  • High‑pressure hydraulic systems in construction equipment

Working pressure 350 bar, burst pressure 1 400 bar; sizes DN6‑DN25 with BSP and SAE UNF threads; conforms to ISO 16028.
