Gear Pump with Pulley Group 2

SKU 312 Categoría:

The Group 2 gear pump with integrated pulley is a compact, belt‑driven hydraulic pump offered in six sizes (9‑35 mm displacement). Made from hardened alloy steel, it provides smooth operation up to 250 bar, with inlet/outlet ports of 118 mm and 150 mm respectively and a 34° pulley angle for standard type‑B V‑belts. Ideal for mobile hydraulics, construction equipment, and industrial machinery. All models share identical core dimensions and are available in stock for immediate delivery. Contact Cohimar for pricing and technical data.

Description

REFERENCIA DERECHA REFERENCIA IZQUIERDA POLEA A B C D E F G α TIPO CORREA
R-2L9DP01R R-2L9IP01R P 118 150 23 35 21,5 17 82,5 34º B
R-2L12DP01R R-2L12IP01R P 118 150 23 35 21,5 17 82,5 34º B
R-2L16DP01R R-2L16IP01R P 118 150 23 35 21,5 17 82,5 34º B
R-2L22DP01R R-2L22IP01R P 118 150 23 35 21,5 17 82,5 34º B
R-2L27DP01R R-2L27IP01R P 118 150 23 35 21,5 17 82,5 34º B
R-2L35DP01R R-2L35IP01R P 118 150 23 35 21,5 17 82,5 34º B
  • Mobile hydraulic systems for construction equipment
  • Agricultural machinery hydraulic circuits
  • Industrial presses and stamping machines
  • Material handling equipment such as forklifts

Integrated pulley with 34° angle for standard type‑B V‑belt; identical core dimensions across all six size variants (A‑G) and pressure rating up to 250 bar.
